型号
Model |
|
FSEP3-2.7 |
FSEP3-3.3 |
FSEP3-4.0 |
FSEP3-4.5 |
平台最大高度
Max.Platform Height |
H (mm) |
2700 |
3300 |
4000 |
4500 |
机器最大高度
Max.Machine Height |
H1 (mm) |
4120 |
5000 |
5400 |
6000 |
底座离地距离
Ground Clearance |
H2 (mm） |
40 |
40 |
40 |
40 |
平台额定载荷
Lifting Rated Capacity |
kg |
300 |
300 |
300 |
300 |
平台尺寸
Platform Size |
mm |
600×640 |
600×640 |
600×640 |
600×640 |
最高驾驶速度(平台降下）
Max.Drive Speed(platform stowed) |
km/h |
4 |
4 |
4 |
4 |
最高驾驶速度(平台升起)
Max.Drive Speed(platform elevated) |
km/h |
1.6 |
1.6 |
1.6 |
1.6 |
最小转弯直径
Min.turning Radius |
mm |
1600 |
1600 |
1600 |
1600 |
最大爬坡能力
Max.Climbing Capacity |
% |
15-20 |
15-20 |
15-20 |
15-20 |
驱动轮尺寸
Driving Wheel Size |
mm |
φ230×80 |
φ230×80 |
φ230×80 |
φ230×80 |
万向轮尺寸
Caster Size |
mm |
φ150X40 |
φ150X40 |
φ150X40 |
φ150X40 |
驱动电机
Driving Motor |
V/Kw |
2×24/0.4 |
2×24/0.4 |
2×24/0.4 |
2×24/0.4 |
举升电机
Lifting Motor |
V/Kw |
24/1.6 |
24/1.6 |
24/1.6 |
24/1.6 |
免维护电池
Batteries |
V/Ah |
2×12/150 |
2×12/150 |
2×12/150 |
2×12/150 |
充电器
Charger |
V/A |
24/15 |
24/15 |
24/15 |
24/15 |
整机长度
Overall Length |
A (mm) |
1530 |
1530 |
1620 |
1620 |
整机宽度
Overall Width |
B (mm) |
700 |
700 |
700 |
700 |
整机高度
Overall Height |
C (mm) |
1830 |
2130 |
1840 |
2000 |
整机重量
Overall Net Weight |
kg |
430 |
430 |
660 |
680 |
